H1Z2Z2-K 1x6mm² Solar Cable 1500V DC | Bexie Energy
🔒 Precio reservado a clientes B2B Acceder / Registrarse
In stock
H1Z2Z2-K 1x6mm² solar cable, halogen-free for photovoltaic systems up to 1500V DC. High UV resistance, thermal stability and suitable for direct burial.
Overview
The H1Z2Z2-K 1x6mm² solar cable from Bexie Energy is a high-quality photovoltaic conductor designed for demanding solar installations, ensuring maximum safety, durability and efficiency in systems up to 1500V DC.
Manufactured according to EN 50618:2014, this halogen-free cable is designed to withstand extreme conditions including UV exposure, high temperatures and direct burial applications.
Main features
- Halogen-free solar cable (LSZH)
- Rated voltage up to 1500V DC
- High UV and weather resistance
- Suitable for direct burial
- Tinned copper conductor class 5
- Low smoke emission in case of fire
Technical specifications
- Cross section: 1×6 mm²
- Standard: EN 50618:2014
- Rated voltage: 1000/1500V DC
- Operating temperature: -40°C to +90°C
- Max conductor temperature: 120°C
- Bending radius: ≥ 6x diameter
Applications
- Residential PV installations
- Industrial solar plants
- Solar module interconnections
- DC string wiring for inverters
- Outdoor and direct burial systems
Maximum safety and durability
The H1Z2Z2-K cable ensures safe photovoltaic installations with high mechanical strength, fire resistance and long service life under extreme environmental conditions.
More information
| Color | Rojo, Negro |
|---|
